Tube End Facing Machine
NFM - 1625
Features :
This is a very COMPACT, LIGHT WEIGHT & POWERPUL
Machine to Face, Bevel & Weld Preparation for Condenser, heat-
Exchanger tubes.Available in Electrical & Pneumatic Version
Drive |
Pneumatic | Electric |
|---|---|---|
Locking Range (mm) |
20-42 | 20-42 |
Ideal Speed (RPM) |
400 | 250 |
Torque (Nm) |
27.5 | 45.0 |
Feeding Stroke (mm |
23 | 23 |
| Pneumatic Power (HP) | 0.60 | N.A. |
| Air Consumption (cfm) | 16 | N.A. |
| Air Pressure (psi) | 90 | N.A. |
| Electric Power (watts) | N.A. | 650 |
| Weight (kg) | 5.5 | 5.5 |
NFM - 3000
Features :
This is a MOST POPULAR & POWERPUL Machine to Face,
Bevel & Weld Preparation for boiler tubes.Available in Electrical
& Pneumatic Version
Drive |
Pneumatic | Electric |
|---|---|---|
Locking Range (mm) |
28-76 | 28-76 |
Ideal Speed (RPM) |
110 |
140 |
Torque (Nm) |
84 | 138 |
Feeding Stroke (mm |
40 | 40 |
| Pneumatic Power (HP) | 0.83 | N.A. |
| Air Consumption (cfm) | 42 | N.A. |
| Air Pressure (psi) | 90 | N.A. |
| Electric Power (watts) | N.A. | 595 |
| Weight (kg) | 9.5 | 11.0 |
NFM - 4500
Features :
This is a HEAVY DUTY, POWERPUL Machine to Face, Bevel &
Weld Preparation for heavy wall thickness tubes. Available in
Electrical & Pneumatic Version
Drive |
Pneumatic | Electric |
|---|---|---|
Locking Range (mm) |
39-104 | 39-104 |
Ideal Speed (RPM) |
60 | 60 |
Torque (Nm) |
220 | 240 |
Feeding Stroke (mm |
40 | 40 |
| Pneumatic Power (HP) | 1.3 | N.A. |
| Air Consumption (cfm) | 40 | N.A. |
| Air Pressure (psi) | 90 | N.A. |
| Electric Power (watts) | N.A. | 1800 |
| Weight (kg) | 21.0 | 23.0 |
NFM - 8000
Features :
This is a HEAVY DUTY, POWERPUL Machine to Face, Bevel &
Weld Preparation for wide range heavy wall thickness tubes.
Available in Electrical & Pneumatic Version
Drive |
Pneumatic | Electric |
|---|---|---|
Locking Range (mm) |
51-203 | 51-203 |
Ideal Speed (RPM) |
40 | 40 |
Torque (Nm) |
240.0 | 240.0 |
Feeding Stroke (mm |
23 | 40 |
| Pneumatic Power (HP) | 1.3 | N.A. |
| Air Consumption (cfm) | 40 | N.A. |
| Air Pressure (psi) | 90 | N.A. |
| Electric Power (watts) | N.A. | 1800 |
| Weight (kg) | 26.5 | 30.0 |
NFM - 12000
Features :
This is a HEAVY DUTY, POWERPUL Machine to Face, Bevel &
Weld Preparation for wide range heavy wall thickness tubes.
Available in Electrical & Pneumatic Version
Drive |
Pneumatic | Electric |
|---|---|---|
Locking Range (mm) |
88-306 | 88-306 |
Ideal Speed (RPM) |
35 | 31 |
Torque (Nm) |
180 | 230 |
Feeding Stroke (mm |
50 | 50 |
| Pneumatic Power (HP) | 1.60 | N.A. |
| Air Consumption (cfm) | 60 | N.A |
| Air Pressure (psi) | 90 | N.A |
| Electric Power (watts) | N.A. | 1400 |
| Weight (kg) | 30.0 | 34.0 |
